Harrier
Heavy lift FPV trainer for payload drops
- Endurance
- 28 min
- Payload
- 1 kg
- Total weight
- 2.58 kg
- Class
- DGCA Small
Harrier is a 480 mm FPV quadrotor of about 2.6 kg, with a servo payload latch and a stabilised gimbal. Pilots use it to practise tactical payload drops under manual FPV control. It carries up to 1 kg and flies for about 20 minutes with that load. An upgrade path to GPS position hold and automatic release has already been worked out.
Specification
The numbers
Physical
- Type
- FPV quadrotor, heavy lift
- Wheelbase
- 480 mm
- AUW
- 2.58 kg / 3.58 kg loaded
- Class
- DGCA Small
Performance
- Endurance
- 25 to 28 min / ~20 min with 1 kg
- Max thrust
- 7.2 kg, T/W 2.79:1 / 2.01 loaded
Payload
- Capacity
- 1.0 kg
- Actuation
- Servo latch, aux ELRS channel
- Gimbal
- 2 axis brushless + day camera
Communications
- Control
- ELRS
- Video
- Premium analog
- Navigation
- None as standard; GPS hold and return to launch upgrade (6C + NavIC)
Specifications shown are design targets. Figures may vary once a system is built to your specific requirements.
Capabilities
What it does well
Payload drop practice
Live training for tactical delivery sorties
Steady aiming
2 axis gimbal for lining up drops
Manual first
Flies without GNSS as standard, with an upgrade ready
Top of the training fleet
The heaviest trainer we make
Next step
Talk to us about Harrier.
Configurations, integration with your equipment, or a variant built to your requirement. Tell us what you need and we will take it from there.
