Titan
Heavy lift defence octocopter with a 5 kg droppable payload
- Endurance
- 30 min
- Payload
- 5 kg
- Total weight
- 27.8 kg
- Class
- DGCA Large
Titan is a foldable X8 octocopter, with its eight motors paired on four arms, built for defence and paramilitary logistics in the mountains. It carries 5 kg of cargo, whether that is food, medicine or a swapped in EW/SIGINT package, over a 15 km round trip. It hovers for 30 minutes with 12 more in reserve, is sealed to IP56, and a crew of two can have it flying in 15 minutes.
Specification
The numbers
Physical
- Type
- X8 coaxial octocopter
- Wheelbase
- 1,300 mm
- AUW
- 27.8 kg (22.8 kg dry)
- Folded
- All four arms fold
- IP rating
- IP56
- Class
- DGCA Large
Performance
- Hover endurance
- 30 min + 12 min reserve
- Ceiling
- 2,000 m AMSL
- Max thrust
- 120 kg at sea level / 100 kg at 2,000 m
- T/W
- 4.3 at sea level / 3.6 at 2,000 m
Payload
- Capacity
- 5 kg, droppable
- Actuation
- Gravity drop release
- Mount
- Modular belly hardpoint, takes an EW/SIGINT swap
Communications
- Control link
- 256 bit AES
- Video
- 256 bit AES encrypted
- Navigation
- NavIC + GPS, INS fallback
Specifications shown are design targets. Figures may vary once a system is built to your specific requirements.
Capabilities
What it does well
Coaxial redundancy
Eight motors on four arms, so it can lose one and keep flying
AI target lock
Detects targets on an onboard AI accelerator, and an operator confirms every lock
Encrypted control
Command and video links use 256 bit AES encryption
Quick to deploy
Folds into a hard case and flies within 15 minutes
